Data products for June 28, 2007
NOTE: CLASIC science flight with CALIPSO underpass at 19:47:06 UTC. At that time the aircraft was approximately 57 m off the subsatellite track.

Support Data
View
Filename
Type
Descriptions and Comments
Calibration File map_07630_28jun07.gif
GIF
 Map showing flight track for this day
Images and Data
View
Filename
Type
Descriptions and Comments
Flight Summary Image for 532 nm imgsum_07630_28jun07_532.gif
GIF
 Flight summary image showing whole flight for 532 nm
Flight Summary Image for 1064 nm imgsum_07630_28jun07_1064.gif
GIF
 Flight summary image showing whole flight for 1064 nm
Flight Summary Image for depolarization imgsum_07630_28jun07_depol.gif
GIF
 Flight summary image showing whole flight for depolarization
The following are 30 minute images showing 355, 532, and 1064 backscatter signals plus depolarizaton ratio for 1064:
Image Segment 1 imgseg01_07630_28jun07.gif
GIF
 Start time = 17:45:31 End time = 18:15:30
Image Segment 2 imgseg02_07630_28jun07.gif
GIF
 Start time = 18:15:31 End time = 18:45:30
Image Segment 3 imgseg03_07630_28jun07.gif
GIF
 Start time = 18:45:31 End time = 19:15:30
Image Segment 4 imgseg04_07630_28jun07.gif
GIF
 Start time = 19:15:31 End time = 19:45:31
Image Segment 5 imgseg05_07630_28jun07.gif
GIF
 Start time = 19:45:32 End time = 20:15:32
Image Segment 6 imgseg06_07630_28jun07.gif
GIF
 Start time = 20:15:33 End time = 20:45:33
Image Segment 7 imgseg07_07630_28jun07.gif
GIF
 Start time = 20:45:34 End time = 21:09:17
The following images and files are for the entire flight:
Layer Boundary File layers_07630_28jun07.txt
TEXT
 Layer boundary file showing type and location of all atmospheric layers sensed
Quick Optical File cipbl_07630_28jun07.txt
TEXT
 Quick optical file showing optical depth and extinction-to-backscatter ratio calculations for a pre-defined cirrus zone and the cloud-cleared Planetary Boundary Layer for 355, 532, and 1064 nm.
ReadMe.txt CIPBL_readme.txt
TEXT
 Text file describing how to interpret and use the quick optical file.
Optical Depth Plots (Cirrus) ciod_07630_28jun07.gif
GIF
 Optical Depth Plots (Cirrus), from the Quick Optical File
Optical Depth Plots (PBL) pblod_07630_28jun07.gif
GIF
 Optical Depth Plots (PBL), from the Quick Optical File
The following are 30 minute images showing extinction and total optical depth:
Extinction Segment Image EXTSEG01_07630_28jun07.gif
GIF
 Start time = 17:45:31 End time = 18:15:30
Extinction Segment Image EXTSEG02_07630_28jun07.gif
GIF
 Start time = 18:15:31 End time = 18:45:29
Extinction Segment Image EXTSEG03_07630_28jun07.gif
GIF
 Start time = 18:45:31 End time = 19:15:30
Extinction Segment Image EXTSEG04_07630_28jun07.gif
GIF
 Start time = 19:15:31 End time = 19:45:30
Extinction Segment Image EXTSEG05_07630_28jun07.gif
GIF
 Start time = 19:45:31 End time = 20:15:29
Extinction Segment Image EXTSEG06_07630_28jun07.gif
GIF
 Start time = 20:15:31 End time = 20:45:30
Extinction Segment Image EXTSEG07_07630_28jun07.gif
GIF
 Start time = 20:45:31 End time = 21:09:17
The following images are for the entire flight:
Final Cloud Image cod_07630_28jun07.gif
GIF
 Cloud Optical Depth Plot (three wavelength)
Final Aerosol Image aod_07630_28jun07.gif
GIF
 Aerosol Optical Depth Plot (three wavelengths)
Total Optical Depth Plot tod_07630_28jun07.gif
GIF
 Total Optical Depth Plot (three wavelength)

Large Binary Output Files
Filename
Type
Descriptions and Comments
NRB_07630_28jun07.xdr
XDR
 NRB Binary Output containing Lidar profiles after instrument corrections but before calibrated backscatter
OP_07630_28jun07.xdr
XDR
 Final Optical Binary Output containing optical properties of every layer sensed, including optical depth, extinction-to-backscatter ratio, and extinction profile for 355, 532, and 1064 nm.
cal_07630_28jun07.final
TEXT
 Request calibration file. This file contains the instrument calibration coefficients used to generate attenuated backscatter data from the NRB binary data.
*Note* Binary output files are large (most files are 500MB).
If you want the binary output files above, click on the filename to download.

Go Back
