Data products for February 6, 2003
NOTE: This is a short pre-THORPEX test flight at Dryden.

Support Data
View
Filename
Type
Descriptions and Comments
Calibration File map_03611_06feb03.gif
GIF
 Map showing flight track for this day
Images and Data
View
Filename
Type
Descriptions and Comments
Flight Summary Image imgsum_03611_06feb03.gif
GIF
 Flight summary image showing whole flight in one wavelength
The following are 30 minute images showing 355, 532, and 1064 backscatter signals plus depolarizaton ratio for 1064:
Image Segment 1 imgseg01_03611_06feb03.gif
GIF
 Start time = 18:24:21 End time = 18:54:02
Image Segment 2 imgseg02_03611_06feb03.gif
GIF
 Start time = 18:54:03 End time = 19:23:43
Image Segment 3 imgseg03_03611_06feb03.gif
GIF
 Start time = 19:23:44 End time = 19:39:03
The following images and files are for the entire flight:
Layer Boundary File layers_03611_06feb03.txt
TEXT
 Layer boundary file showing type and location of all atmospheric layers sensed
Quick Optical File cipbl_03611_06feb03.txt
TEXT
 Quick optical file showing optical depth and extinction-to-backscatter ratio calculations for a pre-defined cirrus zone and the cloud-cleared Planetary Boundary Layer for 355, 532, and 1064 nm.
ReadMe.txt CIPBL_readme.txt
TEXT
 Text file describing how to interpret and use the quick optical file.
Optical Depth Plots (Cirrus) ciod_03611_06feb03.gif
GIF
 Optical Depth Plots (Cirrus), from the Quick Optical File
Optical Depth Plots (PBL) pblod_03611_06feb03.gif
GIF
 Optical Depth Plots (PBL), from the Quick Optical File
The following are 30 minute images showing extinction and total optical depth:
Extinction Segment Image EXTSEG01_03611_06feb03.gif
GIF
 Start time = 18:24:21 End time = 18:54:19
Extinction Segment Image EXTSEG02_03611_06feb03.gif
GIF
 Start time = 18:54:20 End time = 19:24:19
Extinction Segment Image EXTSEG03_03611_06feb03.gif
GIF
 Start time = 19:24:20 End time = 19:39:03
The following images are for the entire flight:
Final Cloud Image cod_03611_06feb03.gif
GIF
 Cloud Optical Depth Plot (three wavelength)
Final Aerosol Image aod_03611_06feb03.gif
GIF
 Aerosol Optical Depth Plot (three wavelengths)
Total Optical Depth Plot tod_03611_06feb03.gif
GIF
 Total Optical Depth Plot (three wavelength)

Large Binary Output Files
Filename
Type
Descriptions and Comments
NRB_03611_06feb03.xdr
XDR
 NRB Binary Output containing Lidar profiles after instrument corrections but before calibrated backscatter
OP_03611_06feb03.xdr
XDR
 Final Optical Binary Output containing optical properties of every layer sensed, including optical depth, extinction-to-backscatter ratio, and extinction profile for 355, 532, and 1064 nm.
cal_03611_06feb03.final
TEXT
 Request calibration file. This file contains the instrument calibration coefficients used to generate attenuated backscatter data from the NRB binary data.
*Note* Binary output files are large (most files are 500MB).
If you want the binary output files above, click on the filename to download.
